The steel bar truss floor deck can bear the operation load and be directly laid out on the beam. The concrete casting can be carried out after simple steel bar construction. Because it can completely replace the form board without the form board installation and dismounting roject,it greatly improves the construction efficiency. It is widely used in structures and building like the multi-story plant building,multi-story ,high rise,super high rise building,various irregular building floor,concrete structure,high speed railway and so on.
1. Small MOQ
2.Superior Quality
3.Competitve Price
4.Fast Delivery Time
| Brand Name | C channel steel |
| Material Grade | 20#,45#,Q195,Q215,Q235B,Q345B, S235JR/S235/S355JR/S355/SS440/SM400A/SM400B.etc. |
| Size | 50*37*5.438kg/m~400*104*71.488kg/m Customer's Requiremnts |
| Length | 3M/6M/Customer's Requiremnts |
| Thickness | 3.0MM~9.0MM or custom |
| Tolerance | ±1% |
| Technique | Hot Rolled/Cold Rolled |
| Material | We can offer carbon,alloy,stainless steelA36，Q235B,Q345B，S235JR/S235/S355JR/S355， SS400/SS440/SM400A/SM400B， 200/300/400 series |
| Product Standard | AiSi, ASTM, bs, DIN, GB, JIS，API.ect. |
| Surface Treatment | Hot dip galvanized/Unistrut Pre-galvanized/Spray/Customized |
| Specification | Sectional size | Area of Section cm2 | Mass kg/m | Moment of inertia cm4 | Section of modulus cm3 | Turning radius cm | |||||||
| H | B | b | c | t | 1x | 1y | Wx | Wy | Rx | Ry | |||
| C10016 | 100 | 50 | 20 | 1.6 | 3.84 | 3.01 | 57.0 | 12.0 | 11.18 | 3.52 | 4.07 | 1.87 | |
| C10020 | 100 | 50 | 20 | 2.0 | 4.80 | 3.77 | 70.4 | 15.0 | 13.81 | 4.45 | 4.05 | 1.87 | |
| C12016 | 120 | 50 | 20 | 1.6 | 4.16 | 3.27 | 82.9 | 17.0 | 14.06 | 5.48 | 4.93 | 2.01 | |
| C12020 | 120 | 50 | 20 | 2.0 | 5.20 | 4.08 | 103.7 | 19.7 | 17.28 | 6.16 | 4.91 | 2.01 | |
| C12025 | 120 | 50 | 20 | 2.5 | 6.50 | 5.10 | 129.60 | 24.2 | 21.60 | 7.56 | 4.90 | 2.01 | |
| C15016 | 150 | 60 | 20 | 1.6 | 4.96 | 3.89 | 170.80 | 25.3 | 22.18 | 5.75 | 6.02 | 2.31 | |
| C15020 | 150 | 60 | 20 | 2.0 | 6.20 | 4.87 | 212.90 | 31.6 | 27.81 | 7.31 | 5.99 | 2.31 | |
| C15025 | 150 | 60 | 20 | 2.5 | 7.75 | 6.08 | 216.9 | 39.6 | 31.16 | 9.11 | 5.96 | 2.32 | |
| C16016 | 160 | 60 | 20 | 1.6 | 5.12 | 4.02 | 200.2 | 25.4 | 25.03 | 6.14 | 6.25 | 2.22 | |
| C16020 | 160 | 60 | 20 | 2.0 | 6.40 | 5.02 | 247.5 | 31.7 | 30.94 | 7.69 | 6.22 | 2.22 | |
| C16025 | 160 | 60 | 20 | 2.5 | 8.00 | 6.28 | 305.0 | 29.7 | 83.13 | 9.16 | 6.17 | 2.22 | |
| C20020 | 200 | 70 | 20 | 2.0 | 7.20 | 5.65 | 417.8 | 34.4 | 43.78 | 9.56 | 7.62 | 2.18 | |
| C20025 | 200 | 70 | 20 | 2.5 | 9.00 | 7.07 | 516.0 | 43.0 | 51.60 | 10.06 | 7.51 | 2.18 | |
| C20030 | 200 | 70 | 20 | 3.0 | 10.80 | 8.48 | 611.7 | 51.6 | 61.17 | 12.14 | 7.53 | 2.19 | |
| C25020 | 250 | 75 | 20 | 2.0 | 8.60 | 6.75 | 804.0 | 53.0 | 64.30 | 10.40 | 9.78 | 2.51 | |
| C25025 | 250 | 75 | 20 | 2.5 | 10.75 | 8.44 | 611.7 | 53.0 | 64.30 | 13.30 | 9.78 | 2.51 | |
| C25030 | 250 | 75 | 20 | 3.0 | 12.90 | 10.13 | 1206.0 | 79.5 | 96.50 | 16.20 | 9.78 | 2.51 | |
| C30030 | 300 | 80 | 20 | 3.0 | 15.6 | 12.80 | 1366.4 | 92.8 | 103.8 | 18.60 | 10.66 | 2.88 | |
| C40030 | 400 | 100 | 30 | 4.0 | |||||||||
