Every day, thousands of construction workers walk across freshly laid metal decking high above the ground, unaware that their safety depends entirely on a temporary system that will be dismantled and discarded within days or weeks. The floor bearing deck—whether composite steel deck, form deck, or cellular deck—is the foundation upon which everything else is built. But during the critical window between deck installation and concrete curing, this seemingly robust surface is dangerously vulnerable. Without adequate temporary shoring, the consequences can be catastrophic.
This article explores why temporary shoring is not just a regulatory checkbox but an indispensable safety measure in modern steel structure construction. We will examine the real-world costs of neglect, the engineering principles that make shoring essential, regulatory requirements from leading jurisdictions, and emerging technologies that are transforming how the industry approaches temporary support systems.
Consider this: a typical floor bearing deck—before concrete topping is poured and cured—consists of corrugated steel sheets, each typically 18 to 22 gauge, spanning between steel beams. While these decks are engineered to carry significant loads once composite action with concrete is achieved, in their pre-concrete state they possess limited structural capacity. Temporary construction loads from workers, equipment, wet concrete, and material storage can easily exceed this capacity if shoring is absent or inadequate.
A composite steel floor deck spanning 12 feet and supporting 4½ inches of wet concrete must carry approximately 55 pounds per square foot of wet concrete weight, plus additional loads from workers, vibrators, and equipment—easily reaching 100 psf or more. Without temporary shoring to transfer these loads safely to lower floors or ground level, floor bearing deck panels can deflect excessively, local buckling can occur at corrugation peaks, or in extreme cases, catastrophic collapse can result.
The statistics are sobering. In fiscal year 2024, federal OSHA investigated 826 worker deaths, with caught-between hazards accounting for approximately 5 percent—about 260 fatalities—of all workplace deaths recorded by OSHA in 2024. Among these caught-between fatalities, trench collapses account for 30 percent, machinery incidents 25 percent, and vehicle pinning 20 percent. While these figures encompass various types of caught-between hazards, the construction industry consistently shows that collapse-related incidents remain a persistent threat despite decades of safety improvements. The U.S. Department of Labor noted that while fatal trench collapses declined nearly 70 percent since 2022 through intensive outreach and enforcement, construction still loses more than 5,000 workers annually in largely preventable incidents.
A global study analyzing 216 documented structure collapse cases across 53 countries between 2005 and 2024 found that while overall collapse incidents decreased modestly in some regions, building collapses—particularly during construction—continued to rise in many countries. The findings confirm the need for better structure monitoring and enforcement of construction regulations.
temporary shoring refers to the temporary support systems installed to sustain the loads imposed during construction until permanent structural elements achieve adequate strength. In the context of steel structure projects, shoring is particularly critical because steel structure erection typically progresses floor by floor, with floor bearing deck installed immediately behind the steel framing. This means that at any given time, multiple floors may be partially complete, with some floor bearing deck supporting fresh concrete while lower floors still await their concrete topping.
Falsework, a broader term encompassing all temporary structures at the construction stage, includes system shoring support systems that are often overlooked in construction projects, thereby causing increasing accidents from falsework collapse. All temporary structures at the construction stage are collectively called falsework, and their importance is frequently underestimated because they are demolished after project completion. Currently, very few specifications exist for falsework design, and many contractors simply calculate the structural strength of falsework based on design specifications for completed structures, leaving the accuracy of these calculations inconclusive.
The 2014 occupational accident statistics from the Council of Labor Affairs show that most occupational accidents occurred in the construction industry, with falls and collapses being the most common accident types. Although system shoring supports are commonly used in construction, no well-defined instructions for installation and required safety facilities have been established to provide a dependable guide.
Building codes and safety regulations worldwide mandate temporary shoring for floor bearing deck installation. The New York City Building Code (Chapter 33) provides one of the most comprehensive frameworks, requiring that bracing and shoring be designed to support maximum loads, with minimum construction loads never less than 100 pounds per square foot. Bracing and shoring must ultimately bear upon permanent structure or earth capable of sustaining the transmitted loads, and design specifications must include criteria for the removal of any temporary bracing or shoring.
Importantly, NYC Building Code §3305.8.6.6 explicitly requires that no decking or section of decking shall be placed on a joist until the joist has been fully installed and braced. Moreover, §3305.8.6.8 mandates that no temporary shoring or bracing shall be removed until a cold-formed steel special inspector has verified that the shoring or bracing is no longer required.
The Washington Administrative Code (WAC 296-155) requires that the minimum total design load for any shoring used in slab and beam structures be not less than 100 pounds per square foot for combined live and dead load, regardless of slab thickness. Shoring must also be designed to resist all foreseeable lateral loads such as wind, cable tensions, inclined supports, and impact loads, with a minimum assumed lateral load of 100 pounds per lineal foot of floor edge or 2 percent of total dead load of the floor, whichever is greater.
The ANSI/SDI C1.0 Standard for Composite Steel Floor Deck specifies that shoring shall be securely in place before the floor deck erection begins, designed and installed in accordance with ACI Building Code Requirements, and left in place until the slab attains 75 percent of its specified design strength and a minimum of seven days. OSHA 29 CFR 1926 Subpart R (Steel Erection) further reinforces that temporary or permanent flooring must be maintained within two stories or 30 feet—whichever is less—below and directly under the portion of each tier of beams on which work is being performed.
Understanding why temporary shoring is critical requires examining the fundamental mechanics of steel structure construction. A steel structure relies on the composite action between structural steel beams and floor bearing deck with concrete topping to achieve designed load capacity. However, in the hours and days immediately after floor bearing deck installation, this composite action does not yet exist. The deck alone, despite its steel construction, is essentially a thin-walled shell structure that must be supported until concrete cures to design strength.
Construction loads during this vulnerable window can be substantial. Concrete wet density is approximately 150 pounds per cubic foot; 4½ inches of wet concrete thus exerts about 56 psf before accounting for reinforcement, forms, construction equipment, workers, and concrete vibrators. Combined loads of 100 psf or more are routine. In projects using motorized carts for concrete placement, design loads must be increased by 25 psf.
The shoring layout must include all details of the specification, including unusual conditions such as heavy beams, sloping areas, ramps, and cantilevered slabs, as well as plan and elevation views. Shoring layout must be prepared or approved by a person qualified to analyze the loadings and stresses induced during the construction process. This requirement reflects the simple reality: improper shoring design is a leading cause of collapse.
A study on temporary shoring failure during concrete placement demonstrated that even when shoring is installed, failures can occur if the design fails to account for eccentric loading, sloping grade conditions, or multiple levels of shoring. The failure mode is sudden; when temporary adjustable telescopic steel shores fail, they provide no warning before collapse. This abrupt failure characteristic makes shoring systems unforgiving of design or installation errors.
Historical case studies reveal the devastating consequences of shoring neglect. In 1973, the improper removal of forms triggered a progressive collapse of the Skyline Plaza in Bailey‘s Crossroads, Virginia, killing 14 construction workers and injuring 34 others. In 1987, a section of the University of Washington football stadium expansion collapsed due to premature removal of temporary guy wires. In 1998, a major scaffold system on a 49-story building in New York’s Times Square collapsed as a result of bracing removal, resulting in one death, several injuries, and hundreds displaced from their residences.
More recently, the 2019 Hard Rock Hotel collapse in New Orleans raised questions about whether temporary shoring supports were removed too quickly after heavy concrete had been poured onto corrugated metal decks. A worker was reportedly heard mocking the engineering in Spanish, noting that a support post appeared bent from too much weight before the catastrophic failure occurred.
These incidents share common patterns: premature removal of shoring, inadequate design loads, improper field modifications, and failure to inspect before concrete placement. In a 2016 OSHA inspection, a Doka shoring post supporting a fifth-floor metal decking was found not to have been inspected immediately prior to concrete being poured, exposing employees to fall hazards. The simple failure to inspect before a critical operation placed lives at risk.
Based on regulatory requirements and industry standards, the following best practices should be implemented for every floor bearing deck installation involving steel structure projects:
The shoring layout must be prepared or approved by a qualified person capable of analyzing loadings and stresses induced during construction. This is not a task for field crews working from rough sketches. Detailed design must account for dead loads, live loads, wind loads, and any other foreseeable lateral loads.
Shoring must be designed for no less than 100 psf combined live and dead load. For projects using motorized carts, an additional 25 psf must be added to the design load. Wind loads and impact loads during concrete placement must be considered, with minimum lateral load of 100 pounds per lineal foot of floor edge or 2 percent of total floor dead load.
All load-carrying timber members must be minimum 1500 f Stress Grade construction grade lumber. Sills for shoring must be sound, rigid, and capable of carrying maximum intended loads without settlement or displacement. When shoring from soil, the bearing surface must be evaluated by an engineer to ensure adequate capacity.
The NYC Building Code requires that deviations from approved shoring drawings that are not immediately corrected be brought to the attention of the registered design professional who prepared the drawings. No person, material, or equipment shall be permitted on any joint or decking until all members, fasteners, shoring, and bracing have been properly installed.
Shoring must remain in place until the concrete slab attains 75 percent of its specified design strength and a minimum of seven days, as specified by ANSI/SDI C1.0. Premature removal is a leading cause of collapse.
The fall protection threshold height requirement is 6 feet (1.8 meters) for all work covered by construction safety regulations. This includes floor bearing deck installation and related activities.
The construction industry is increasingly embracing technology to enhance temporary shoring safety. Building Information Modeling (BIM) now informs the layout of temporary support systems before any steel or timber arrives on site. BIM-based tools enable 3D modeling of system shoring support facilities, providing a communication platform for engineers, shoring contractors, and labor safety personnel.
One study used BIM technology with Autodesk Revit to draw the actual status of system shoring support erection on construction sites, proposing corresponding preventive safety measures for safety passages and stairs. The study concluded that through BIM integration, construction falsework safety can be significantly enhanced.
Sensor technologies are also transforming shoring safety. Concrete monitoring systems using wireless sensors measure concrete temperature and calculate compressive strength in real time, sending data wirelessly to engineers and temporary works designers. These smartphone-sized sensors help contractors determine the optimal stripping time for shoring, improving safety while reducing unnecessary waiting periods. IoT-based real-time monitoring of falsework is being implemented at several pilot sites, including projects with the Hong Kong Housing Authority, where force and inclination sensors are synchronized with falsework installation.
These technological advances, combined with 4D BIM for visualizing construction sequencing and wearable sensors for worker location tracking, represent the future of temporary works safety management. The design and execution of temporary structures have a decisive impact on a project‘s schedule, cost, safety record, and environmental impact—and technology is making each of these factors more manageable than ever before.
Even experienced contractors fall into patterns of error that compromise temporary shoring safety. The following mistakes are particularly prevalent:
Failure to update shoring layouts for field conditions. Shoring layouts prepared during design may not account for field variations in beam placement, floor openings, or access requirements. These deviations must be brought to the attention of the registered design professional.
Insufficient lateral bracing. Shoring systems designed only for vertical loads can fail when wind, equipment impacts, or concrete placement induce unexpected lateral forces. Lateral bracing must be provided at regular intervals.
Stacking materials on deck before shoring verification. Loads placed on decking before shoring is verified can create localized overstressing. The 2010 OSHA inspection where a worker was killed after a long beam struck him occurred because the decking was in place but unstable, yet bundles of decking were placed on it anyway.
Premature shoring removal. The temptation to remove shoring to free equipment or accelerate schedules has caused countless collapses. Shoring must remain in place until concrete achieves adequate strength.
Inadequate soil support. When shoring bears on soil rather than permanent structure, soil capacity must be evaluated. Settlement can cause differential loading and eventual collapse.
temporary shoring may be a disposable element of construction, but its importance is permanent. The temporary support system installed beneath a floor bearing deck represents the thin line between controlled construction and catastrophic collapse. In steel structure projects where multiple floors are under simultaneous construction and floor bearing deck is being installed continuously, the complexity of coordinating shoring across multiple levels requires careful engineering, rigorous inspection, and unwavering attention to safety protocols.
The statistics make clear that while progress has been made—with fatal trench collapses declining nearly 70 percent since 2022 through aggressive enforcement and education—construction still loses more than 5,000 workers annually in largely preventable incidents. No temporary structure that will be dismantled within weeks is worth sacrificing a human life.
As Assistant Secretary for Occupational Safety and Health Douglas Parker observed: “Reducing worker deaths means embracing an approach that makes worker health and safety a core value in every workplace”. For the floor bearing deck and steel structure industry, that core value begins with temporary shoring. Design it properly. Install it correctly. Inspect it thoroughly. Remove it only when strength is verified. Because when safety is treated as temporary, the consequences are permanent.
